How to Wire a Fender® Guitar (DVD) with Dan Erlewine



Universal DVD, 34 minutes

6 in stock

Add to Wishlist Browse Wishlist



Guitar electronics demystified!


Learn how to wire your Fender guitar cleanly for great sound, and discover how its electronics work.

Now on DVD! Our 34-minute DVD with famed repairman Dan Erlewine demonstrates complete wiring jobs step-by-step, and will give you the confidence to do the job right. It also features special animations to help you understand how the pickups and electronic components function.

Dan presents complete wiring jobs for Strat® and Tele® using our Golden Age pickups. With the diagrams supplied in our wiring kits as a guide, he shows you how to install the pickups, switch, pots and output jack cleanly and professionally. Proper grounding and copper-foil shielding techniques are demonstrated to help reduce noise, and Dan also shares a handy tip for properly locating a Tele® rhythm pickup to fit the pickguard.

Disc contents
Introduction: Dan Erlewine
Basic soldering tools
Wiring a Strat
How a volume control works
How a tone control works
Treble bypass cap
Reverse-wind, reverse-polarity
How a Strat circuit works
Wiring and shielding a Tele
Using a multimeter

The DVD format includes easy menu selections for quickly reviewing and finding the information you need.

This DVD is not region-specific and is intended for worldwide use.
